3 Main Differences Between Relay and Contactor

Relays and contactors are two essential components in electrical systems for controlling power flow. Although similar in function, their design and application make them suitable for different purposes.

This article discusses three major differences between relays and contactors: functions, attributes, and applications. By understanding the difference between a relay and a contactor, one can select the right component when constructing electrically powered projects or assembling electrical systems for specific needs.

Difference Between Relay and Contactor: Function

Relays and contactors both play a vital role in many electrical applications. In simple terms, if we talk about contactor vs relay, relays can be used for control signal switching, amplification and isolation, and low-current operations.

Regarding power-switching tasks demanding higher levels of current or continuous-duty operation, contactors are preferable. This section will examine the difference between a relay and a contactor in terms of the functions of both components.

The Function of Relay

Relays play a crucial role in electrical systems with the following functions:

• Control Signal Switching: Relays act as switches to control the current flow in a circuit based on a control signal. They provide a means to open or close a circuit, allowing the control signal to activate or deactivate the load circuit.
• Signal Amplification and Isolation: Relays can amplify weak control signals, enabling them to control larger loads or devices. They also provide isolation between the control and load circuits, safeguarding sensitive control components from high voltages or currents.
• Low-Current Applications: Relays are well-suited for applications with low-current requirements. They can handle small currents, ranging from milliamperes to a few amperes. This makes them suitable for controlling electronic circuits, microcontrollers, sensors, and other low-power devices.

The Function of Contactor

Contactors serve specific purposes in electrical systems, characterized by the following functions:

• Power Switching: Contactors are designed to handle the switching of high currents in power circuits. They enable the control circuit to switch heavy loads, such as electric motors, lighting systems, and industrial machinery.
• Continuous Duty Operation: Contactors are built to withstand continuous operation without overheating or malfunctioning. They can handle long periods of operation, making them suitable for applications where the load needs to be continuously powered.
• High-Current Applications: Contactors excel in high-current applications, typically ranging from tens to thousands of amperes. They are constructed with robust materials and heavy-duty contacts to handle the demands of large currents, ensuring reliable and safe operation in high-power devices and systems.

Differences Between Relay and Contactor: Design and Construction

This section focuses on the design and construction aspects of contactors and relays. Relays are characterized by their coil and armature design and the contacts they employ. Contactors also feature a coil and armature design, along with their specific type of contacts.

Design and Construction of Relay

Relays are designed and constructed with the following key elements:

• Coil and Armature: At the core of a relay are two major components – the coil and armature. When energized by an electrical control signal, the coil generates a magnetic field. This field causes movement in the armature, usually spring-loaded, to return to its default position when the coil is de-energized.
• Contacts: On relays, sets of contacts are actuated when the armature moves. These contacts come in three types – normally open (NO), normally closed (NC), or changeover (CO) – which dictate whether they open or close a circuit as they’re triggered.

Design and Construction of Contactor

Contactors are designed and constructed with the following elements:

• Coil and Armature: Like relays, contactors also utilize the concept of a coil and armature. The energization of the coil results in a magnetic field that causes the armature to move, allowing it to open or close the contacts in the contactor.
• Contacts: Power contacts are used for contractors because they can handle larger currents than those found in relays. Furthermore, these contacts are designed to be more durable for power-switching applications with materials that will meet such demands.

Differences Between Relay and Contactor: Applications

This section will explore the relay and contactor differences in terms of applications. Relays are widely used in vehicles, appliances, and other consumer electronics, while contractors are frequently employed in industry settings and lighter systems. Understanding how these components operate can be of great use for various applications.

Applications of Relay:

Relays are utilized in various applications, including:

• Automotive Electronics: Relays play a crucial role in automotive electronics, enabling the control of electrical systems such as lighting, motors, and ignition. They are used in automotive relays to turn on headlights, control window motors, activate cooling fans, and more.
• Household Appliances: Relays are employed in various household appliances for control and switching purposes. They can be found in refrigerators, air conditioners, washing machines, and televisions. Relays enable the control and protection of electrical circuits within these appliances, ensuring efficient and safe operation.

Applications of Contactor:

Contactors find their applications in various fields, including:

• Lighting Systems: Contactors play a major role in lighting systems, particularly large-scale installations. In commercial and industrial settings, contactors switch energy suppliers to high-power lighting fixtures, like streetlights, stadium lights, and indoor lighting circuits. These contractors maintain the reliable operation of these important systems.
• Industrial Machinery: Contactors provide valuable power switching and control functions in industrial machinery. They are essential for controlling electric motor systems, pumps, conveyor belts, and various other types of heavy machinery. Contractors are invaluable in handling high-current loads safely and ensuring efficient industrial equipment operations.

Choose Reliable Contactor by BENY

BENY New Energy is the world leader in supplying PV protection components. Our 30+ years of experience in the electrical industry make us a top choice for innovation and dependability. We specialize in solar DC protection design, production, and marketing and offer custom-made and brand-building protection solutions that meet the highest quality standards.

Our combined boxes are crafted from durable materials and assembled precisely by our quality control team. Businesses will receive discounts for larger orders and a 5-year warranty with every purchase.

Our AC Contactor boxes BBWX-1/1 (1 input 1 output) and BBWX-1/3 (1 input 3 output) offer IP65 protection with a maximum voltage of 400V and current output up to 16A/20A, respectively. Also, we offer customized solutions to suit the consumers’ project needs perfectly.

Conclusion

Relay and contactor are both necessary building blocks of electrical systems. When choosing the right application component, it’s important to understand the distinctions between relays and contactors.

BENY New Energy is a trusted supplier of superior quality contractors that will contribute to a safe and efficient electrical system operation. Give us a call today!
